Elevated Water Tank Steel Towers Hot Dipped Galvanized Steel Structures
- Brand: ZHM-Steel-Tower
- Type: ZHM-Steel-Tower
- Price: RMB
- Promotion: RMB ( 0 Customers Bought)
Content Index:
Application: Steel Workshop, Steel Structure Platform, Steel Fabricated House, Structural Roofing, Frame Part, Water Tank Support
Type: Light Section SteelStandard: GB, ASTM, DIN, JIS
Trademark: Low-alloy High-tensile Structural Steel, XGZBT
Forming: Hot-Rolled Steel
Connection Form: Bolt Connection
Customization: Available
Basic Information:
Model NO.ZHMBT-001
Member Type: Steel Truss
Type of Steel For Building Structure: High-Strength Steel
Carbon Structural Steel:Q355, Q345, Q235
Residential Wall Structure: Bottom Wall Beam
Height:3m-30m
Live Load: 5~500ton
Earth Quake Seismic Grade: 7 Degree typically, unless noted otherwise
Transport Package:Seaworthy Pallet, ocean containers
Specification:ASTM,AS/NZS, CE, ISO
Origin:Zhejiang, China
HS Code: Steel Structure and Accessories 73089000
Production Capacity: 5000tons Per Month
There are many experiences in steel structure manufactured and exported since 2007.
1. ISO,CE and AWS Certificate
2. 22 years production experience
3. OEM is welcome
4. High quality with reasonable price
5. Can produce various height and structural tower
6. Monthly production capacity can reach 5000 Metric tons
7. Performance Standard
Elevated Water Tank Steel Towers specification:
• H section steel column, beam, with angle steel support
• Access ladder with safety cage
• Designed a walkway around the tank
• Design certificate by registered professional engineer
• Surface finished: galvanized or painted
• The tower height can be 3m, 6m, 10m, 12m, 15m ... ...
• All the steel parts are prefabricated in factory, just assemble together with bolts & nuts.
• Installation service are available.
Steel Water tank specification:
|
Water tank material |
Hot-dipped galvanized steel as per BS/EN ISO 1461 or ASTM A123 |
|
|
Water tank capacity |
1m³ ~ 5000 m³ |
|
|
Water tank size |
According to the water volume or customer's request |
|
|
Using life |
≥20 years |
|
|
Tank panel |
Panel material |
Galvanized steel (Recommended ), Enamel, FRP etc. |
|
Panel size |
1220mm*1220mm, 1000mm*1000mm |
|
|
Panel thickness |
5mm, 4.5mm, 3mm, 2.5mm, 2mm, 1.5mm (It is different according to the tank dimension) |
|
|
Acceessories |
Bolt. nut & washers |
hot-dipped galvanized steel |
|
Sealing material |
Non-toxic P.V.C foam tape shall be used in between the joints |
|
|
Covers |
from 1.4mm to 3.0mm of thickness hot-dipped galvanized material |
|
|
Ladder |
hot-dipped galvanized material |
|
|
Level Indicator |
Glass |
|
