Introduction
Modular Steel Bridge (Panel Type)/Bailey Bridges

The Bailey Bridge Legacy Lives On

Bailey bridging solutions are used in a variety of applications employing either the original or improved designs. While then regarded as a warfare breakthrough, the Bailey Bridge in the post-war era is a great civil engineering innovation and booster to socioeconomic development. This is because of the structure’s continued deployment in establishing vital connections and delivering supplies, especially to remote areas. Bailey bridges are used to extend help to places hit and isolated by natural disasters, war, or terrorism. They are instrumental in bringing-out tribes to civilized communities to access proper education and medical, political, and social rights.

Modular Steel Bridge (Panel Type) | Bailey Bridge


ZHM Huawu Steel-HD-100 Bailey Bridge

Among the crafts of ZHM Huawu Steel in steel bridges is the ZHM Huawu Steel-HD-100 Bailey Bridge, or the so-called 321-Panel Type Bridge. The bridge panels are composed of welded high-grade structural steel elements. The girders are lightweight composite panels connected by sturdy steel pins. Panels and components of the steel bridge are easy to handle and transport, can be interchanged, and are simple to erect and disassemble. They can also be assembled into different forms of panel bridges according to their span length and transportation requirement.

HD-100 Bailey Bridge or 321-Panel Type Bridge is suitable for short to medium spans or light to moderate loads.  It can stand to a maximum free span length of 51 meters (167.30 feet), with a deck net width of 4 meters (13.10 feet). Being lightweight, this bridge type is guaranteed for emergency and difficult situations. Different configurations and dimensions of bridge panels can also be custom-built.

Modular Steel Bridge (Panel Type) | Bailey Bridge


ZHM Huawu Steel-HD-200 Bailey Bridge

ZHM Huawu Steel-HD-200 model is an upgrade of the Bailey bridge HD-100 in terms of load capacity and span length. With panel heights increased to 2.13 meters (7 feet), it can cover maximum free span of 60.96 meters (200 feet) for single lane width and 45.72 meters (150 feet) for double lane width.

In the assembly of HD-200, joints between panels are located alternately against the joints between reinforcement chords to reduce inelastic deformation due to oversized pinholes. Pre-arch or camber is employed to counter deflection of the bridge at the mid-span. All bolted connections are equipped with

orienting sleeves to ensure that compression forces are absorbed by the sleeve and tensions by the bolts.This helps to increase the life span of the bolts and generally the safety of the panel bridge. Composite braces against wind loads are also provided and connected to the transoms or girders to enhance the overall stability of the bridge especially against side bending.

Modular Steel Bridge (Panel Type) | Bailey Bridge


The model is suitable for load designs such as HS-15, HS-20, HS-25, HL-93, Pedrail-50, and more.

Product and Project Photos

Modular Steel Bridge (Panel Type) | Bailey Bridge


Why ZHM Huawu Metal Modular Steel Bridge (Panel Type) | Bailey Bridges  ?


Reliable_and_customized_DesignsG
Cutting_edge_designing_process
Free_online_Pricing_System
Easy_Bolt-by-number_Assembly
Reliable and Customized Designs Cutting Edge Designing Process Free Online Price System Easy Bolt-by-number Assembly
Over_two_decades_of_Experiencey
Value_Engineering_for_Money
Unmatched_In_Quality
Excellent_Customer_Service
Over Two Decades of Experience Value For Money Unmatched in Quality and Craftmanship Excellent Customer Service

Would you like to see more information and images of ZHM Huawu Steel's Modular Steel Bridge (Panel Type) | Bailey Bridges ? Visit our Photo Gallery.
