Large Span Conical Dome
ZHM engineered, fabricated, and installed multiple atriums at the Oil & Technology Center Building.
The atriums consist of structural glass and steel creating a “jeweled” appearance. The largest atrium spans 22meter wide by 25meter long by 13meter high. The glazing utilizes ZHM’s Point Supported Glass and Edge Clamped Glass Systems, with structural support featuring ZHM’s Tension Rod System. The atriums span a total of 1,415m2.
Project Specifications
|
SIZE:
|
1,550 sq m
|
|
TECHNICAL SYSTEMS USED
|
Kugel Knoten Aluminum Supported Glass |
Why ZHM Huawu Steel Large Span Domed skylight Atrium Space Frames | Architecturally Exposed Steel?
 |
 |
 |
 |
| Reliable and Customized Designs | Cutting Edge Designing Process | Free Online Price System | Easy Bolt-by-number Assembly |
 |
 |
 |
 |
| Over Two Decades of Experience | Value For Money | Unmatched in Quality and Craftmanship | Excellent Customer Service |
Would you like to see more information and images of ZHM’s Large Span Domed skylight Atrium Space Frames | Architecturally Exposed Steel ? Visit our Photo Gallery.
